|materiał:||Cewka z drutu okrągłego Incoloy 800 UNS N08800||typu:||drut ze stopu drutu|
|Gatunek:||Stop niklu 800 800H 800HT 901 925 926||Kształt:||arkusz / pasek / rura / wrie / bar / ect|
|standardowe:||UNS, DIN, ASTM, SAE, ISO, ASME||aplikacji:||Przemysł|
|Specyfikacja:||BV, SGS, ISO||Wymiary:||Dostosowane|
|Pakiety:||W wiązkach z wodoodpornym materiałem||Przystań:||Shanghai|
nickel steel alloy,
corrosion resistant steel alloys,
high temperature alloys
Incoloy 800 UNS N08800 alloy round bar pipe plate wire coil Incoloy 800 800H 800HT 901 925 926
Incoloy800 Fe - Ni - Cr base deformation of high temperature corrosion resistant alloy solid solution strengthening, used under 1000 ℃, Incoloy800 has excellent high temperature corrosion resistance and good process performance, organizational stability is good, the machining and welding performance is good, the use of hot and cold processing are easy, suitable for making demanding condition of corrosive medium, high temperature parts of long working hours.
Standard Specifications and certifications include:
Chemical Composition Of Incoloy 800
|Product Name||alloy round bar pipe plate wire coil|
|Production Process||Cold Drawn,Cold Rolled,Hot Rolled,Bright Anneal etc|
|Size||5.5-110mm(Hot rolled), 2-50mm(Cold drawn),110-500mm(Forged)|
|Standard||ASTM EN DIN GB ISO JIS|
|Pickling,Bright; No.1,2B,No.4,BA,8K Satin,Brush,Hairline,Mirror,Polished
180 grits,320 grits,400 grits,600 grits,800 grits polished
|Application||Constructions feilds and ship building industries Petroleum,Chemical industries,War and electiciy industries. Food processing and medical industries. Boiler heat cxchangers,Machinery and hardware feilds.|
Incoloy 800 has the following features:
1. Excellent corrosion resistance in extremely high temperature water-based media up to 500℃
2. Good stress corrosion resistance
3. Good processing ability
Metallographic structure of Incoloy 800:
Incoloy 800 is a face-centered cubic lattice structure.
Extremely low carbon content and improved Ti:C ratio increase structural stability and maximum resistance to sensitization and intercrystalline corrosion.
Low temperature annealing at about 950℃ ensures fine grain structure.
Incoloy 800's corrosion resistance:
Incoloy 800 can withstand many corrosive media corrosion.
Its high nickel content makes it have good stress corrosion cracking resistance in water corrosion condition.
High chromium content makes it have better resistance to spot corrosion and crack corrosion.
The alloy has good properties
Resistance to nitric and organic acids, but in sulfuric and hydrochloric acid resistance is limited.
In addition to the possibility of spot corrosion in halides, it has good corrosion resistance in oxidizing and non-oxidizing salts.
In water, steam as well as steam, air, dioxide
The mixture of carbon also has good corrosion resistance.
Incoloy 800 process performance and requirements:
1. The temperature range is 1200℃ ~ 950℃, and the cooling mode is water quenching or rapid air cooling.
2. In order to obtain the best performance and anti-creep property, solid solution treatment should be carried out after hot processing.
3. The material can be directly fed into the furnace which has been heated to 1200℃. After sufficient time of heat preservation, it can be quickly released and processed within the specified temperature range.
When the material temperature falls below the hot working temperature, it needs to be reheated.
1. The work hardening rate is higher than that of austenitic stainless steel, so the processing equipment should be selected.
Cold processing materials should be solid solution heat treatment state, and in large amount of cold processing should be carried out intermediate annealing.
2. If the amount of cold processing is greater than 10%, it is necessary to conduct secondary solid solution treatment on the workpiece.
Welding process of incoloy800
Suitable for any traditional welding process and the same material or other metal welding, such as tungsten inert gas welding, plasma arc welding, manual sub-arc welding, metal inert gas welding, melting inert gas welding, pulse arc welding is the preferred solution.In the case of manual arc welding, (Ar+He+H2+CO2) is recommended as the protective gas.
Incoloy800 is Alloy chemical industry, nuclear generator, nitric acid cooler, acetic anhydride cracking tube, heat exchange equipment, heat exchange tube, etc.
Incoloy is a nickel ferrochrome alloy designed for oxidation and carbonation at elevated temperatures.Incoloy alloy has many kinds: common such as Incoloy800, Incoloy800H, Incoloy800HT, Incoloy825, Incoloy840, Incoloy901, Incoloy925, Incoloy20, Incoloy330, Incoloy 25-6mo, etc.The alloy contains a small amount of the metallic elements molybdenum and copper.In reductive acid and oxidizing acid, it has good corrosion resistance, as well as good resistance to stress corrosion cracking, pitting and crevice corrosion.It has excellent corrosion resistance to sulfuric acid and phosphoric acid.The alloy has good cold and hot working properties and is easy to be formed and welded.The main products of this alloy are rods, tubes, plates, strips, wires and forgings, etc. It is mainly used in the chemical, petrochemical, nuclear and rare metal refining industries.
